SMP series adapter
Lair microwave adapters are commonly used to facilitate connections between two different types of connectors. Some adapters can also achieve conversion and protection of ports, allowing for compatibility with various frequently used cable assemblies or equipment. In addition to straight-head adapters, Lair Microwave also offers right-angle heads, flange panels, wall penetrations, and more, to meet your diverse needs.
Product Features
High-Frequency Coverage、High Precision and Low Loss、High Reliability and Durability、Convenient Design
Typical Applications
Communications and Networking、National Defense and Aerospace、Cutting-Edge Technology and Testing
| Product | Frequency（GHz） | S21（dB） | NF（dB） | P1dB（dBm） | Vd（V）/Idd（mA） | Packge |
| HXLN1001 | 0.01~5 | 22 | 0.7 | 22 | 5/68 | DFN/Die |
| HXLN1002 | 0.01~5 | 22 | 0.7 | 22 | 5/68 | DFN/Die |
| HXLN1003 | 0.1~6 | 23 | 1.5 | 21 | 5/75 | SHX89/Die |
| HXLN1004 | 0.1~6 | 23 | 1.5 | 21 | 5/75 | Die |
| HXLN1005 | 0.45-0.65 | 24.5 | 0.55 | 22 | 5/85 | Die |
| HXLN1006 | 0.5~4 | 18.6 | 1.6 | 22.5 | 5/104 | SHX89/Die |
| HXLN1007 | 0.5~4 | 18.6 | 1.6 | 22.5 | 5/104 | Die |
| HXLN1008 | 0.5~6 | 22 | 0.7 | 22 | 5/70 | DFN/Die |
| HXLN1009 | 0.5~6 | 22 | 0.68 | 22.5 | 5/70 | DFN/Die |
| HXLN1010 | 0.7~1.25 | 21 | 0.4 | 20.5 | 5/85 | QFN/Die |
| HXLN1011 | 0.7~1.25 | 20 | 0.5 | 20 | 5/130 | QFN/Die |
| HXLN1012 | 1~2 | 21 | 0.8 | 20 | 5/20 | DFN/Die |
| HXLN1013 | 1.5~2.3 | 22 | 0.7 | 25 | 5/135 | QFN/Die |
| HXLN1014 | 2~4 | 33 | 0.4 | 20 | 5/95 | Die |
| HXLN1015 | 2~4 | 33.5 | 0.4 | 21 | 5/109 | Die |
| HXLN1016 | 2~4 | 32 | 0.4 | 19.5 | 5/95 | Die |
| HXLN1017 | 2~4 | 28 | 1.1 | 8.7 | 5/39 | Die |
| HXLN1018 | 2~6 | 14 | 1.5 | 20.8 | 5/56 | Die |
| HXLN1019 | 2~18 | 26.3 | 1.25 | 9.2 | 5/59 | Die |
| HXLN1020 | 2~20 | 17 | 1.5 | 14.5 | 5/68 | Die |
| HXLN1021 | 5~6 | 25.5 | 0.62 | 15 | 5/27 | Die |
| HXLN1022 | 5.9~8.5 | 15 | 1.14 | 14.9 | 5/16 | QFN/Die |
| HXLN1023 | 7~13 | 28 | 0.7 | 4 | 3.3/12 | Die |
| HXLN1024 | 8~12 | 30 | 0.85 | 7.6 | 5/26 | Die |
| HXLN1025 | 12~18 | 27.5 | 0.7 | 2 | 3.3/11 | Die |
| HXLN1026 | 14~18 | 30 | 0.8 | 8 | 5/12 | Die |
| HXLN1027 | 17~22 | 26.5 | 1 | 6.5 | 5/13 | Die |
| HXLN1028 | 17~22 | 28.5 | 0.9 | 6.3 | 5/15 | Die |
| HXLN1029 | 27~31 | 22 | 1.8 | 3 | 3.3or5/12.5 | Die |
| HXLN1030 | 32~38 | 32 | 1.7 | 2 | 3.3/13.5 | Die |
| HXLN1031 | 0.1~4 | 18.5 | 1.3 | 8 | 5/33mA | DFN/Die |
